MODEL | SF-600w | |
Rated Output Power | 600VA/600W | |
INPUT | ||
Bypass voltage Range | 176VAC~264VAc | |
Frequency Range | 40Hz~70Hz | |
OUTPUT | ||
Rated Output Voltage | 220VAC | |
output Frequency | 5OHz/60Hz | |
Peak Power | 1100VA | |
overload Capacity | 630VA-70OVA, Turn off the output after 30s; 70OVA-800VA, Turn off the output after 5s; 8ooVA-90OVA, Turn off the output after 2s; | |
Conversion Efficiency | 91% | |
Waveform | Pure sine wave | |
USB/12V | USB 5.0V2.2A*4; 12V2.0A*2 | |
BATTERY | ||
DC Voltage | 18V~25V(24v) | |
Recharging Current | 5A±10% | |
Battery Capacity | 13.2Ah | |
overvoltage | 25.5±1% | |
overvoltage Recovery Point | 23.9±1% | |
Low Battery Alarm | 19±2% | |
Battery Low Voltage Shutdown | 18V±2% | |
Protection | Overcharge protection, overtemperature protection, overload protection battery overvoltage protection, output short circuit protection | |
SOLAR CHARGE | ||
PV Input Voltage (VOC) | 30V~75V | |
MPPT Voltage | Battery oltage+4V~60V | |
Charge Current | 5A±10% | |
MAX. Conversion Efficiency | 95% | |
ENVIRONMENT | ||
Humidity | 0%~90% (No condensation) | |
Temperature | -10°C~45°C | |
Altitude | <2000m | |
Cooling | Wind cooling | |
Fan Noise | ≤26dB(A) | |
FEATURE | ||
D x W x H(mm) | 327x138x178 | |
N.W(kg) | 3.9kg |
